XLB-S22T Screw bar floor Locking Screw Machine
- Equipment description
- Equipment operating instructions
Double Batch and Double Platform Structure
Supports two different screw, different torsion lock, when locking one
screw, left and right can work independently at the same time.
Pre-Play, Pre-Play and Post-Play, the two modes are set freely
Safety grating
Equipment Size: 1080*725*1450mm(L*W*H)
Working dimensions:160(X)*500(Y)*60(Z)
Lock-in speed: average<1.8S/piece
Screw taking mode: suction type
Positioning accuracy: +0.02 mm
Driving mode: imported servo+ lead screw
Control mode: PLC touch screen
It has the functions of leakproof lock, slippery teeth and automatic detection of float height
Electrical requirements: 220VAC power supply, 0. 4-0.8MPa air source
Screw range: M1.4-M4
